Description
ebm-papst K3G560-PC04-01 (also known as K3G560PC0401) is an industrial high-efficiency RadiPac backward-curved EC centrifugal fan module engineered with an integrated support bracket and precision aerodynamically shaped inlet nozzle. Driven by an advanced 3-phase M3G150-NA permanent-magnet brushless EC motor, the 560 mm (22.05 in) 5-blade aluminum impeller achieves up to 12,515 CFM (21,265 m³/h) of airflow and static pressure capabilities reaching 5.22 in H₂O (1,300 Pa). The unit integrates active power electronics in a rugged die-cast aluminum housing offering continuous 5,000 W power management across wide 380–480 VAC 50/60 Hz industrial grids. Built for mission-critical air handling, it features an IP55 sealed enclosure, integrated RS-485 MODBUS RTU digital communication, configurable 0–10 V/PWM control interfaces, and dual ball bearings for durable S1 continuous duty.
Key Features
- High-Efficiency RadiPac Impeller: Delivers up to 12,515 CFM (21,265 m³/h) using a 5-blade aerodynamic backward-curved aluminum wheel.
- Wide-Range 3-Phase EC Motor: Operates efficiently across 380–480 VAC 50/60 Hz supplies with passive PFC and active phase-failure monitoring.
- Integrated Digital & Analog Control: Supports RS-485 MODBUS RTU networking, 0–10 VDC/PWM speed inputs, and direct 4–20 mA sensor interfaces.
- Auxiliary Sensor Power Supplies: Provides isolated onboard +10 VDC (10 mA) and +20 VDC (50 mA) outputs for external transducers.
- Rugged Heavy-Duty Architecture: Constructed with galvanized sheet steel mounting structure, black-coated steel support struts, and IP55 protection.
- Comprehensive Motor Diagnostics: Includes integrated PID regulation, soft starting, locked-rotor prevention, and a programmable alarm status relay.
Technical Specifications
| Manufacturer | ebm-papst |
|---|---|
| Manufacturer Part Number (MPN) | K3G560-PC04-01 |
| Alternate Part Number | K3G560PC0401 |
| Integrated Motor Model | M3G150-NA |
| Product Series | RadiPac |
| Product Category | EC Centrifugal Fans |
| Fan / Component Type | EC Centrifugal Module (Backward-Curved, Single-Inlet with Support Bracket) |
| Phase & Supply Type | 3~ Three-Phase AC |
| Rated Voltage | 400 VAC |
| Operating Voltage Range | 380 to 480 VAC |
| Frequency | 50 / 60 Hz |
| Speed (RPM) | 1760 RPM |
| Power Rating | 5000 W |
| Power Input (Ped at Optimum Duty) | 5.03 kW |
| Rated Current | 7.70 A |
| Max. Airflow (Free Air) | 12515 CFM (21265 m³/h) |
| Airflow at Optimum Efficiency | 6922 CFM (11760 m³/h) |
| Max. Static Pressure | 5.22 in H₂O (1300 Pa) |
| Pressure Increase at Optimum Efficiency (pfs) | 4.16 in H₂O (1035 Pa) |
| Noise Level (Inlet Sound Pressure LpAin) | 77 to 95 dB(A) |
| Impeller Size | Ø 560 mm (22.05 in) |
| Number of Blades | 5 |
| Impeller Material | Aluminium sheet |
| Mounting Plate Material | Sheet steel, galvanised |
| Support Bracket Material | Steel, coated in black |
| Inlet Nozzle Material | Sheet steel, galvanised |
| Electronics Housing Material | Die-cast aluminium |
| Rotor Surface | Coated in black |
| Direction of Rotation | Clockwise, seen on rotor |
| Inlet Nozzle Pressure Tap Calibration | k-factor: 348 |
| Accessory Mounting Provision | Mounting holes for FlowGrid |
| Bearing Type | Dual Maintenance-Free Ball Bearings |
| Installation Position | Shaft horizontal (support struts vertical) or rotor on bottom; rotor on top on request |
| Condensation Drainage Holes | Rotor-side |
| Operating Mode / Duty Cycle | S1 Continuous Operation |
| Weight | 68 kg (149.9 lbs) |
| Termination & Cable Specs | Integrated terminal box via compression glands (Cable Ø 4-10 mm & Ø 9-16 mm) |
| Control / Signal Features | RS485 MODBUS RTU, 0-10 VDC / PWM control input, integrated PID controller, parameter set switching |
| Auxiliary Power Outputs | +10 VDC (±3%, max. 10 mA) and +20 VDC (+25/-10%, max. 50 mA), short-circuit proof |
| Analog Inputs & Outputs | 2x Analog inputs (0-10 V / 4-20 mA selectable), 1x Analog output (0-10 VDC, max. 5 mA) |
| Digital Inputs | 3x Digital inputs (Din1 enable/reset, Din2 parameter set 1/2, Din3 controller normal/inverse) |
| Status Relay Output | Form C changeover alarm relay (NO/COM/NC), rated 250 VAC / 2 A (AC1) |
| Motor Protection | Locked-rotor protection, reverse polarity, thermal overload protection for motor & electronics, line undervoltage / phase failure detection |
| Touch Current (IEC 60990) | <= 3.5 mA (Measuring network Fig. 4, TN system) |
| Electrical Protection Class | Class I (with customer protective earth) |
| Insulation Class | Class F |
| Ingress Protection (IP) | IP55 |
| Moisture / Environmental Protection Class | H1 |
| Overall Efficiency (ηes) | 70.2% |
| Efficiency Grade (N) | 73.3 (ErP 2015 target: 62) |
| Operating Temperature Range | -25°C to +40°C (-13°F to +104°F) |
| Storage / Transport Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| EMC Interference Immunity | Acc. to EN 61000-6-2 (Industrial Environment) |
| EMC Interference Emission | Acc. to EN 61000-6-3 (Household Environment) |
| Standards & Compliance | EN 61800-5-1, CE, UL 1004-7 + 60730, C22.2 No. 77 + CAN/CSA-E60730-1, EAC, EU 327/2011 (ErP) |
