Description
The ebm-papst D2D133-AB02-07 (also known as D2D133AB0207) is an industrial dual-intake forward-curved AC centrifugal blower with integrated scroll housing, powered by an external rotor M2D068-DF three-phase motor across a 180 mm × 173.5 mm × 215.0 mm (7.09 in × 6.83 in × 8.46 in) compact footprint. Operating on 400 VAC in star (Y) connection at 50/60 Hz, the unit delivers up to 485 CFM (825 m³/h) airflow and nominal operating speeds reaching 2170 RPM (50 Hz) and 2640 RPM (60 Hz) under 225 W and 215 W power ratings. Robust mechanical engineering features a galvanized sheet steel scroll housing, black-painted forward-curved steel impeller, galvanized steel guard grille, and maintenance-free dual ball bearings rated for IP44 ingress protection in continuous S1 duty. Electrical termination is provided via an axial silicone multi-conductor cable (3× 0.5 mm²) terminating in 2.8 mm × 1.0 mm flat quick-connect receptacles.
Key Features
- High-Efficiency Aerodynamics: Dual-inlet forward-curved galvanized steel impeller generates 485 CFM against continuous industrial back pressures.
- Three-Phase 400VAC Motor: Integrated external rotor M2D068-DF motor supports star wiring for stable continuous S1 operation.
- Heavy-Duty Construction: Rugged galvanized sheet steel scroll housing with RAL 9006 powder-coated intake guard grille.
- Harsh Environment Sealing: Rated IP44 with F2-2 environmental moisture protection and integrated rotor condensation drainage holes.
- Flexible Power Termination: Axial high-temperature silicone cable fitted with crimped 2.8×1 mm flat quick-connect slide receptacles.
Technical Specifications
| Manufacturer | ebm-papst |
|---|---|
| Manufacturer Part Number (MPN) | D2D133-AB02-07 |
| Alternate Part Number | D2D133AB0207 |
| Integrated Motor Model | M2D068-DF |
| Product Series | D2D133 |
| Product Category | AC Blower Fans |
| Fan / Component Type | Centrifugal Blower, Dual-Intake, Forward-Curved, with Housing (Without Flange) |
| Phase & Supply Type | 3~ Three-Phase AC |
| Rated Voltage | 400 VAC |
| Motor Wiring Configuration | Star (Y) Connection |
| Frequency | 50 Hz / 60 Hz |
| Speed (RPM) | 2170 RPM (50 Hz) / 2640 RPM (60 Hz) |
| Power Rating | 225 W (50 Hz) / 215 W (60 Hz) |
| Rated Current | 0.37 A (50 Hz) / 0.34 A (60 Hz) |
| Airflow | 485 CFM (825 m³/h) at 100 Pa (50 Hz) |
| Minimum Back Pressure | 0.40 in H₂O (100 Pa) at 50 Hz / 1.00 in H₂O (250 Pa) at 60 Hz |
| Maximum Pressure Increase | 1.28 in H₂O (320 Pa) at 165 CFM (50 Hz) |
| Fan / Impeller Size | 133 mm (5.24 in) |
| Overall Dimensions (L × H × D) | 180.0 mm × 173.5 mm × 215.0 mm (7.09 in × 6.83 in × 8.46 in) |
| Housing Material | Sheet Steel, Galvanized |
| Impeller Material | Sheet Steel, Galvanized and Painted Black |
| Guard Grille Material | Steel, Galvanized and Coated with White-Aluminum Plastic (RAL 9006) |
| Rotor Surface | Painted Black |
| Motor Suspension | Motor Mounted with Brackets on One Side |
| Bearing Type | Maintenance-Free Ball Bearings |
| Direction of Rotation | Clockwise, viewed toward rotor (Reversible by swapping two phases) |
| Installation Position | Any (Universal Mounting) |
| Condensation Drainage Holes | Located on Rotor Side |
| Operating Mode / Duty Cycle | Continuous Operation (S1) |
| Weight | 4.8 kg (10.58 lbs) |
| Termination & Cable Specs | Axial Silicone Cable 3× 0.5 mm² with 3x Crimped Flat Push-On Receptacles 2.8 mm × 1.0 mm |
| Wiring Pinout / Connection | L1 = Black, L2 = Blue, L3 = Brown (Protective Earth via customer chassis grounding) |
| Motor Protection | Requires External Overload / Circuit Breaker Protection (No factory internal thermal overload protector) |
| Electrical Protection Class | Class I (with customer connection of protective earth) |
| Touch Current (IEC 60990) | < 0.75 mA (Measuring Circuit Fig. 4, TN System) |
| Insulation Class | Class F |
| Moisture / Environmental Protection Class | F2-2 |
| Ingress Protection (IP) | IP44 (Installation- and position-dependent per EN 60034-5) |
| Operating Temperature Range | -25 °C to +80 °C (-13 °F to +176 °F) at 50 Hz / -25 °C to +75 °C (-13 °F to +167 °F) at 60 Hz |
| Storage Temperature Range | -40 °C to +80 °C (-40 °F to +176 °F) |
| Standards & Compliance | CE, EN 60335-1, RoHS Compliant (ROHS3) |
Applications
The ebm-papst D2D133-AB02-07 dual-inlet centrifugal blower is widely deployed in commercial HVAC air handling units, ducted ventilation systems, air curtains, and climate control plenums requiring continuous forced convective circulation. It provides targeted thermal dissipation across industrial machinery, packaging automation, reflow soldering tunnels, drying ovens, and medium-voltage electrical control switchgear. Maintenance and operations teams regularly rely on this blower for direct OEM replacement in process equipment, commercial refrigeration condensers, and factory clean air delivery systems.
