Description
ebm-papst 514F is a precision compact DC tubeaxial cooling fan measuring 50 x 50 x 15 mm (1.97 x 1.97 x 0.59 in), engineered for forced-air spot cooling in space-constrained industrial systems. Operating on a 24 VDC nominal supply across a 21.6 to 26.4 VDC input range, it delivers 11.8 CFM (20 m³/h) of airflow at a rated speed of 5000 RPM while drawing only 0.9 W of power with a 30 dB(A) acoustic profile. The assembly is constructed with a rugged fiberglass-reinforced PBT plastic housing, fiberglass-reinforced PA plastic impeller, and a smooth Sintec sleeve bearing system offering an L10 service life of 50,000 hours at 20 °C. Integrated impedance protection guards against reverse polarity and blocked-rotor conditions, with electrical connection made via stripped and tin-plated AWG 28 lead wires.
Key Features
- Aerodynamic Performance: Delivers 11.8 CFM (20 m³/h) of targeted airflow at 5000 RPM with low 30 dB(A) acoustic emission.
- Durable Reinforced Construction: Features fiberglass-reinforced PBT housing and PA impeller for structural stability in compact thermal enclosures.
- Sintec Bearing System: Provides smooth, quiet operation with an extended service life rating of 50,000 hours at 20 °C.
- Comprehensive Motor Protection: Integrated impedance protection shields the motor circuitry against reversed polarity connections and locked-rotor stall conditions.
- Industrial Compliance: Globally certified under CE, UL, CSA, and VDE standards for safety across OEM equipment architectures.
Technical Specifications
| Manufacturer | ebm-papst |
|---|---|
| Manufacturer Part Number (MPN) | 514F |
| Product Series | 500 F |
| Product Category | DC Axial Fans |
| Fan / Component Type | DC Tubeaxial Fan |
| Phase & Supply Type | DC |
| Rated Voltage | 24 VDC |
| Operating Voltage Range | 21.6 to 26.4 VDC |
| Speed (RPM) | 5000 RPM |
| Power Rating | 0.9 W |
| Airflow | 11.8 CFM (20.0 m³/h) |
| Static Pressure | 0.120 in H₂O (30.0 Pa) |
| Sound Pressure Level | 30 dB(A) |
| Sound Power Level | 4.5 Bel |
| Airflow Direction | Exhaust over struts |
| Dimensions (L × H × D) | 50 × 50 × 15 mm (1.97 × 1.97 × 0.59 in) |
| Mounting Hole Pitch | 42.0 mm (1.65 in) |
| Housing Material | Glass-fiber reinforced PBT plastic |
| Impeller Material | Glass-fiber reinforced PA plastic |
| Bearing Type | Sintec sleeve bearing |
| Direction of Rotation | Counterclockwise, viewed toward rotor |
| Weight | 0.027 kg (0.060 lbs) |
| Termination & Cable Specs | 2 wire leads, AWG 28, TR 64, stripped and tin-plated |
| Motor Protection | Protection against reverse polarity and blocked rotor |
| Locked-Rotor Protection | Impedance protection |
| Operating Temperature | -20 to +70 °C (-4 to +158 °F) |
| Service Life (L10 at 20 °C) | 50000 h |
| Standards & Compliance | VDE, CSA, UL, CE, RoHS |
Applications
ebm-papst 514F axial cooling fan is deployed across compact electronics assemblies requiring targeted forced-air heat dissipation. It provides spot cooling for 1U server chassis, embedded industrial PCs, PoE networking switches, and telecom optical transceivers. Additionally, this compact unit serves as an essential thermal component in benchtop laboratory instruments, automated test fixtures, and medical diagnostic analyzers.
