Description
The ebm-papst 4606X is a heavy-duty, high-performance compact AC tubeaxial cooling fan engineered in an industry-standard 119 x 119 x 38 mm (4.69 x 4.69 x 1.50 in) square form factor. Operating on a 115 VAC supply, this rugged unit incorporates a shaded-pole AC motor that delivers 106.0 CFM (180.1 m³/h) of airflow at a rated speed of 3100 RPM while consuming just 18.0 W. Designed for extreme durability in demanding thermal environments, the fan features an all-metal die-cast housing, a stamped sheet-steel impeller, precision dual ball bearings, and convenient 2-pin flat quick-connect terminal lugs.
Key Features
- All-Metal Rugged Construction: Die-cast metal frame and sheet-steel impeller withstand extreme industrial temperatures and mechanical stress.
- Precision Ball Bearings: Heavy-duty dual ball bearing system permits continuous maintenance-free operation across any mounting orientation.
- High Airflow Delivery: Aerodynamically optimized blade geometry delivers 106 CFM of forced-air cooling in high-impedance electrical enclosures.
- Simplified Plug Termination: Integrated 2-pin flat terminal plug connectors facilitate rapid drop-in installation and streamline field replacement.
- Global Safety Certification: Fully certified to VDE, UL, and CSA safety standards with ISO 4762 M3 mounting compliance.
Technical Specifications
| Manufacturer | ebm-papst |
|---|---|
| Manufacturer Part Number (MPN) | 4606X |
| Product Series | 4600X |
| Product Category | AC Axial Fans |
| Fan / Component Type | Tubeaxial Fan |
| Phase & Supply Type | 1~ Single-Phase AC |
| Rated Voltage | 115 VAC |
| Frequency | 60 Hz |
| Speed (RPM) | 3100 RPM |
| Power Rating | 18.0 W |
| Airflow | 106.0 CFM (180.1 m³/h) |
| Noise Level | 51.0 dB(A) |
| Airflow Direction | Intake over struts |
| Direction of Rotation | Clockwise (looking at rotor) |
| Dimensions (L × H × D) | 119.0 × 119.0 × 38.0 mm (4.69 × 4.69 × 1.50 in) |
| Housing Material | Die-cast metal |
| Impeller Material | Sheet steel (metal) |
| Bearing Type | Ball bearing |
| Mounting Position | Any shaft position (horizontal or vertical) |
| Balancing Grade | 2.5 |
| Mounting Screw Size | ISO 4762 – M3 degreased, without washer |
| Max. Flange Mounting Torque | 160 N·cm (1.42 lb·ft) |
| Weight | 0.550 kg (1.21 lbs) |
| Electrical Connection / Termination | 2-pin flat plug terminals |
| Ingress Protection (IP) | IP20 |
| Standards & Compliance | CSA, UL, VDE, CE, RoHS3 |
Applications
The ebm-papst 4606X axial cooling fan is engineered specifically for mission-critical thermal management in factory automation and high-reliability industrial infrastructure. It is widely installed across variable frequency drive (VFD) chassis, motor control centers (MCC), programmable logic controller (PLC) cabinets, and CNC machining centers. Maintenance technicians and OEM builders also rely on this unit for heat dissipation in un鬆
