Description
The ebm-papst W6D910-GB01-01 (also known as W6D910GB0101) is an industrial high-capacity three-phase AC axial fan engineered with an integrated M6D138-NA external rotor motor and a heavy-duty square full nozzle measuring 1070 mm (42.13 in) in outer flange width. Operating on 400 VAC at 50 Hz with dual Delta/Star (Δ/Y) wiring capabilities, it delivers up to 28,260 m³/h (16,633 CFM) of airflow and reaches up to 160 Pa (0.642 in H₂O) maximum back pressure at 920 RPM with a 2020 W rated power draw. Aerodynamic propulsion is driven by a 5-blade HyBlade structure featuring sheet aluminum inserts overmolded with PP plastic, paired with an IP54-rated cast aluminum rotor and pre-galvanized coated sheet steel housing. The fan integrates an internal thermal overload protector (TOP) with basic insulation and terminal box connectivity, supporting reliable continuous S1 duty across an ambient envelope of -40 °C to +60 °C.
Key Features
- Aerodynamic HyBlade Impeller: Five sickle-shaped composite blades with sheet aluminum inserts overmolded in polypropylene ensure high efficiency and low noise.
- Dual-Speed Δ/Y Operation: Dual Delta and Star winding connections provide flexible airflow outputs of 28,260 m³/h and 25,660 m³/h.
- Rugged Square Nozzle Housing: Pre-galvanized sheet steel frame with black plastic coating provides rigid structural mounting and optimized inlet flow geometry.
- Thermal Overload Protection: Built-in TOP thermal contacts provide continuous winding temperature monitoring to protect the M6D138-NA motor from thermal runaway.
- Industrial Ingress & Corrosion Defense: Sealed to IP54 standards with F3-1 environmental protection class, rotor/stator condensation drainage, and robust Class F insulation.
- ErP 2015 Efficiency Compliance: Surpasses European eco-design regulations with an overall static efficiency rating of 38.4% and an efficiency grade of N42.9.
Technical Specifications
| Manufacturer | ebm-papst |
|---|---|
| Manufacturer Part Number (MPN) | W6D910-GB01-01 |
| Alternate Part Number | W6D910GB0101 |
| Integrated Motor Model | M6D138-NA |
| Product Series | HyBlade S series |
| Product Category | AC Axial Fans |
| Fan / Component Type | AC axial fan with square full nozzle |
| Phase & Supply Type | 3-Phase AC (3~) |
| Rated Voltage | 400 VAC (Δ / Y) |
| Frequency | 50 Hz |
| Speed (RPM) | 920 RPM (Δ, Max Load) / 760 RPM (Y, Max Load) / 955 RPM (Δ, Free Air) |
| Power Rating | 2020 W (Δ, Max Load) / 1390 W (Y, Max Load) |
| Rated Current | 4.62 A (Δ, Max Load) / 2.60 A (Y, Max Load) |
| Max. Current Draw | 4.62 A (Δ) |
| Starting Current | 18.6 A (Δ) / 6.2 A (Y) |
| Airflow | 16,633 CFM (28,260 m³/h, Δ Free Air) / 15,103 CFM (25,660 m³/h, Y Free Air) |
| Static Pressure / Max. Back Pressure | 0.642 in H₂O (160 Pa, Δ) / 0.422 in H₂O (105 Pa, Y) |
| Pressure Increase (Optimum ErP) | 0.582 in H₂O (145 Pa) |
| Overall Efficiency (ηes) | 38.4% (ErP 2015 Req.: 35.5%) |
| Efficiency Grade (N) | 42.9 (ErP 2015 Req.: 40) |
| Sound Pressure Level (LpAin) | 69 to 72 dB(A) (Intake side, 1 m) |
| Sound Power Level (LwAin / LwAout) | 76 to 79 dB(A) (Intake) / 76 to 79 dB(A) (Outlet) |
| Airflow Direction | “V” (Exhaust over struts) |
| Direction of Rotation | Clockwise, viewed toward rotor |
| Impeller Size | Ø 910 mm (35.83 in), 5 blades |
| Blade Pitch | -5° |
| Housing Dimensions (Flange) | 1070 mm × 1070 mm (42.13 in × 42.13 in) |
| Total Depth | 293.5 mm (11.56 in) |
| Mounting Hole Pitch | 4x Ø10 mm holes on 990 mm × 990 mm bolt centers |
| Cable Gland Thread | M20 × 1.5 (Cable Ø 7 to 14 mm, tightening torque 2 ± 0.3 Nm) |
| Housing Material | Sheet steel, pre-galvanized and coated with black plastic (RAL 9005) |
| Guard Grille Material | Steel, coated with black plastic (RAL 9005) |
| Impeller Blade Material | Sheet aluminum insert, overmolded with PP plastic |
| Rotor Surface | Cast in aluminum |
| Terminal Box Material | Polypropylene (PP) plastic |
| Bearing Type | Dual ball bearings |
| Condensation Drainage Holes | On rotor and stator sides |
| Installation Position | Any |
| Operating Mode / Duty Cycle | S1 (Continuous operation) |
| Weight | 52.4 kg (115.5 lbs) |
| Electrical Hookup / Termination | Internal terminal box via cable gland |
| Wiring Pinout / Connection | Δ / Y connections: L1 = U1 (Black), L2 = V1 (Blue), L3 = W1 (Brown), W2 (Yellow), U2 (Green), V2 (White), TOP (2x Gray), PE (Green/Yellow) |
| Motor Protection | Thermal overload protector (TOP) with basic insulation |
| Touch Current (IEC 60990) | <= 3.5 mA (Measuring circuit Fig. 4, TN system) |
| Electrical Protection Class | Class I (with customer connection of protective earth) |
| Insulation Class | Class F |
| Moisture / Environmental Protection Class | F3-1 |
| Ingress Protection (IP Rating) | IP54 |
| Operating Temperature Range | -40 °C to +60 °C (-40 °F to +140 °F) |
| Storage / Transport Temperature | -40 °C to +80 °C (-40 °F to +176 °F) |
| Standards Compliance | EN 60034, EN 61800-5-1, CE, ErP 2015 (EU 327/2011) |
| Product Approvals | EAC, VDE |
Applications
The ebm-papst W6D910-GB01-01 axial fan is primarily engineered for large-scale outdoor refrigeration condensers, industrial fluid coolers, and dry cooling towers requiring dependable high-volume air movement. It is widely installed in commercial air conditioning chillers, rooftop air handling units, and industrial evaporator stations across cold-storage logistics facilities. The rugged square nozzle architecture also serves heavy-duty process heat exchange packages and factory ventilation plenums operating in aggressive weather environments.
