Description
ebm-papst 5314/2HP (also cross-referenced as 53142HP) is an industrial-grade DC Axial Fans tubeaxial cooling fan engineered for high-density forced convection cooling, measuring 139.6 x 139.6 x 50.8 mm (5.50 x 5.50 x 2.00 inches) and operating on nominal 24 VDC. The unit delivers a maximum unimpeded volumetric airflow of 203.0 CFM (345 m³/h / 5.68 m³/min) and up to 280 Pa (1.12 in H₂O) static pressure at a rated rotational speed of 5000 RPM while consuming 28.4 W. Constructed with a die-cast aluminum frame and a fiberglass-reinforced PA plastic impeller, the assembly provides high structural rigidity against vibration and mechanical stress. Drive functionality is maintained by an electronically commutated external rotor motor supported by dual precision ball bearings for unrestricted multi-axis mounting orientation. Electrical interface is executed via three discrete 310 mm lead wires with integrated open-collector tachometer frequency monitoring, backed by locked-rotor protection and reverse polarity defense.
Key Features
- High-Flow Aerodynamic Output: Delivers 203.0 CFM (345 m³/h) and up to 1.12 in H₂O (280 Pa) static pressure to overcome dense flow resistance in ducted electronics.
- Die-Cast Metal Frame Construction: Built with a rugged die-cast aluminum housing and UL94 V-0 fiberglass-reinforced impeller for harsh industrial duty.
- Precision Dual Ball Bearings: Engineered with premium dual-race ball bearings ensuring continuous S1 operation and extended L10 service life across -20°C to +65°C.
- Integrated Tachometer Output: Outfitted with an open-collector speed sensor (/2 suffix) generating discrete pulses per revolution for automated RPM supervisory control.
- Comprehensive Motor Protection: Incorporates active electronic reverse polarity defense and automatic restart lockout protection in stalled rotor conditions.
Technical Specifications
| Manufacturer | ebm-papst |
|---|---|
| Manufacturer Part Number (MPN) | 5314/2HP |
| Punctuation-Free MPN | 53142HP |
| Product Series | 5300 |
| Subcategory | DC Axial Fans |
| Fan Design Type | Tubeaxial Cooling Fan |
| Nominal Voltage | 24 VDC |
| Operating Voltage Range | 16.0 ~ 30.0 VDC |
| Supply Voltage Type | Direct Current (DC) |
| Rated Power Consumption | 28.4 W |
| Rated Current Draw | 1.18 A |
| Rated Rotational Speed | 5000 RPM |
| Maximum Airflow | 203.0 CFM (345 m³/h / 5.68 m³/min) |
| Maximum Static Pressure | 1.12 in H₂O (280 Pa) |
| Acoustic Noise Level | 64.0 dB(A) |
| Nominal Search Frame Size | 140 x 140 x 51 mm (5.5 x 5.5 x 2.0 in) |
| Exact Physical Dimensions | 139.6 x 139.6 x 50.8 mm (5.50 x 5.50 x 2.00 in) |
| Mounting Hole Pitch | 122.2 x 122.2 mm (4.81 x 4.81 in) |
| Mounting Hole Diameter | 4.3 mm (0.169 in) |
| Housing / Frame Material | Die-Cast Aluminum |
| Impeller Material | Fiberglass-Reinforced PA Plastic (UL94 V-0) |
| Bearing System | Precision Dual Ball Bearings |
| Direction of Rotation | Clockwise (Looking at Rotor Face) |
| Direction of Airflow | Exhaust Over Struts |
| Electrical Termination | 3 Lead Wires (AWG 22, TR 64, stripped/tinned) |
| Wire Lead Length | 310 mm (12.2 in) |
| Wire Pinout Definition | Red (+24V), Black (GND), White (Tachometer / Speed Sensor) |
| Signal / Control Interface | Open-Collector Tachometer Output (Speed Sensor) |
| Motor Protection | Electronic Locked-Rotor Protection & Reverse Polarity Protection |
| Operating Temperature Range | -20°C to +65°C (-4°F to +149°F) |
| Storage Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Service Life (L10 at 40°C) | 70,000 Hours |
| Service Life (L10 at Max Temp) | 45,000 Hours |
| Ingress Protection Rating | IP20 |
| Insulation Class | Class E |
| Product Weight | 900 g (1.98 lbs) |
| Agency Approvals | VDE, CSA, UL, CE |
| Environmental Compliance | RoHS Compliant, REACH Affected |
| Export Control Classification Number (ECCN) | EAR99 |
| Harmonized Tariff Schedule (HTSUS) | 8414.59.6590 |
Applications
Primary applications include integration into telecommunications base stations, power conversion inverters, high-density server racks, and industrial variable frequency drives requiring high static pressure dissipation. Deployed as a direct form-fit-function OEM replacement component within automation control cabinets, medical laser power racks, and semiconductor test equipment. Engineered specifically to sustain stable volumetric airflow through tightly packed electronic assemblies, complex air baffles, and ducted heat sinks.
